| Truck Model | ZZ4257V3641W |
| Truck Brand | SINOTRUK-HOWO |
| Dimension (LxWxH) (unloaded)mm | 10500×3550×3950 |
| Approaching angle/ Departure angel (°) | 32/74 |
| Overhang (front/rear) (mm) | 1578/700 |
| Min Turning Radius(m) | <9m |
| Wheel base (mm) | 3600+1400 |
| Max. Driving speed (km/h) | 95 |
| Front axle loading capacity (kg) | 7000 |
| Rear axle loading capacity(kg) | 2*16000 |
| Curb weight (kg) | 15500 |
| Traction weight (kg) | 55000 |
| Engine Model | Model | D12.42(EURO II),420hp,6-cylinder in line, 4-stroke, water-cooled, turbo-charged & inter-cooled, direct injection |
| Rated Power(kw/rpm) | 309/2000 |
| Make SINOTRUCK (CNHTC), Euro II emission standard, Thermostat with 71ºC opening begin, Rigid fan
Engine protection. |
| Transmission | Model | SINOTRUK HW19710 transmission ,10 forward and 2 reverse |
| Steering system | Model | ZF8118 Steering Gear Box ,hydraulic steering with power assistance.
(Left hand driving) |
| Front axle | SINOTRUK STR steering drive Front Axle with drum brakes. |
| Transfer case | 2000 |
| Rear axle | SINOTRUK 2*16000kg Double Reduction Drive Axle, Pressed axle housing, central single reduction with planetary wheel reduction and
with differential locks between wheels and axles,ratio:4.8;
strengthened design, loading capacity and reliability have been increased greatly. |
| Wheels &Tire | Rims:8.5-20 10 hole-steel ;Tyres:12.00R20 radial tyre with 1 Spare tire. |
| Electrical system | Electrics Operating voltage | 24V,negative grounded |
| Starter | 24V,7.5 Kw |
| Batteries | 2x12 V,165 Ah |
| horn,headlamps,fog lights,brake lights,indicators and reverse light. |
| Oil Tank | 400L fuel tank |
| Fifth | 90#(3.5 inch) |
| Packing | Nude Pack.The packing of the commodity shall be in accordance with the export standard packing of the manufacturer,be suitable for
long distance transportation of ocean and inland. The Seller shall be take measures against moisture,shocks and rust according to
the special needs of the commodity . |
